Haemodialysis Machine W-T6008S
- /
- China
- 30 days
- 5000pcs/monthly
Individuation Treatment
-Patients' treatment files can be restored.
-Variety profiles of sodium, UF rate, carbonate, heparin flow, dialysate flow, temperature for individual treatment.
-Convenient process for sequential dialysis(Dialysis←→IUF)and high-low sodium sequential dialysis.
-Single/double needle dialysis.
-Bicarbonate and acetate dialysis.
Individuation Treatment
-Patients' treatment files can be restored.
-Variety profiles of sodium, UF rate, carbonate, heparin flow, dialysate flow, temperature for individual treatment.
-Convenient process for sequential dialysis(Dialysis←→IUF)and high-low sodium sequential dialysis.
-Single/double needle dialysis.
-Bicarbonate and acetate dialysis.
Safety design
-Reliability and safety treatments are ensured by double safety monitoring system.
-Forcibly self- test of hydraulic, blood line and monitoring system ensure the safety and reliability of machine.
-Hydraulic system leakage monitoring system ensure the safety of treatment.
-Ultrasonic and optional monitor on venous line ensure the safety of blood return.
-Daily disinfection modes can be preset, all disinfection condition can be record.
-Monitoring system of AP, VP and TMP enable abnormal alarms more quickly.
-Double-stage endotoxin filtration( HDF-online), ensure the substitution fluid meets AAMI standards.
With ISO13485, ISO9001, IEC60601 |
15-inch LCD touch screen |
Double needle dialysis treatment |
Balance chamber + UF pump |
UF control system with sealed double volume balancing chamber |
8 kinds of UF profiling to meet different clinical application requirements |
With Na, Bicarbonate and UF profiling |
Standby battery - The standby battery can supply power for 30 minutes |
Isolated UF |
HD, HF, HDF treatment |
Self-checking function |
Information display function of display screen |
Audible & visual alarm |
Technical data: |
|
Model | :W-T6008S |
Size(H*W*L) | :142cm x 53cm x 55cm |
Floor area | :65*45cm2 |
Weight | :appox. 85KG |
Input power | :1500W |
Circuit voltage | :100—240Vac |
Standby battery | :30 minutes |
Water inlet pressure | :0.1Mpa~0.6Mpa, 15P.S.I~60P.S.I |
Water inlet temperature | :5℃~30℃ |
Working environment | :10℃~30℃ at relative humidity ≦70% |
Storage environment | :5℃~40℃, at relative humidity ≦80% |
